4. 1 CARGA TRANSMITIDA POR EL PESO DEL MURO
Pmu = P.e. x e x h
Pmu = 1.800 Kg/m3 (ó18 kN/m3) x 0,30 m x 8,00 m
5. 1 CARGA TRANSMITIDA POR EL PESO DEL MURO
Pmu = P.e. x e x h
Pmu = 1.800 Kg/m3 (ó18 kN/m3) x 0,30 m x 8,00 m
Pmu = 4.320 Kg/m (ó 43,20 kN/m)
6. 1 CARGA TRANSMITIDA POR EL PESO DEL MURO
Pmu = P.e. x e x h
Pmu = 1.800 Kg/m3 (ó18 kN/m3) x 0,30 m x 8,00 m
Pmu = 4.320 Kg/m (ó 43,20 kN/m)
2
CARGA TRANSMITIDA POR EL TECHO
Pte = q x a
7. 1 CARGA TRANSMITIDA POR EL PESO DEL MURO
Pmu = P.e. x e x h
Pmu = 1.800 Kg/m3 (ó18 kN/m3) x 0,30 m x 8,00 m
Pmu = 4.320 Kg/m (ó 43,20 kN/m)
2
CARGA TRANSMITIDA POR EL TECHO
Pte = q x a
Pte = 200 Kg/m2 (ó 2 kN/m) x 2.00 m
8. 1 CARGA TRANSMITIDA POR EL PESO DEL MURO
Pmu = P.e. x e x h
Pmu = 1.800 Kg/m3 (ó18 kN/m3) x 0,30 m x 8,00 m
Pmu = 4.320 Kg/m (ó 43,20 kN/m)
2
CARGA TRANSMITIDA POR EL TECHO
Pte = q x a
Pte = 200 Kg/m2 (ó 2 kN/m2) x 2.00 m
Pte = 400 Kg/m (ó 4 kN/m)
9. 1 CARGA TRANSMITIDA POR EL PESO DEL MURO
Pmu = P.e. x e x h
Pmu = 1.800 Kg/m3 (ó18 kN/m3) x 0,30 m x 8,00 m
Pmu = 4.320 Kg/m (ó 43,20 kN/m)
2
CARGA TRANSMITIDA POR EL TECHO
Pte = q x a
Pte = 200 Kg/m2 (ó 2 kN/m2) x 2.00 m
Pte = 400 Kg/m (ó 4 kN/m)
3
CARGA TRANSMITIDA POR EL ENTREPISO
Pep = q x a
10. 1 CARGA TRANSMITIDA POR EL PESO DEL MURO
Pmu = P.e. x e x h
Pmu = 1.800 Kg/m3 (ó18 kN/m3) x 0,30 m x 8,00 m
Pmu = 4.320 Kg/m (ó 43,20 kN/m)
2
CARGA TRANSMITIDA POR EL TECHO
Pte = q x a
Pte = 200 Kg/m2 (ó 2 kN/m2) x 2.00 m
Pte = 400 Kg/m (ó 4 kN/m)
3
CARGA TRANSMITIDA POR EL ENTREPISO
Pep = q x a
Pep = 1.000 Kg/m2 (ó 10 kN/m2) x 2.00 m
11. 1 CARGA TRANSMITIDA POR EL PESO DEL MURO
Pmu = P.e. x e x h
Pmu = 1.800 Kg/m3 (ó18 kN/m3) x 0,30 m x 8,00 m
Pmu = 4.320 Kg/m (ó 43,20 kN/m)
2
CARGA TRANSMITIDA POR EL TECHO
Pte = q x a
Pte = 200 Kg/m2 (ó 2 kN/m2) x 2.00 m
Pte = 400 Kg/m (ó 4 kN/m)
3
CARGA TRANSMITIDA POR EL ENTREPISO
Pep = q x a
Pep = 1.000 Kg/m2 (ó 10 kN/m2) x 2.00 m
Pep = 2.000 Kg/m (ó 20 kN/m)
12. 1 CARGA TRANSMITIDA POR EL PESO DEL MURO
Pmu = P.e. x e x h
Pmu = 1.800 Kg/m3 (ó18 kN/m3) x 0,30 m x 8,00 m
Pmu = 4.320 Kg/m (ó 43,20 kN/m)
2
CARGA TRANSMITIDA POR EL TECHO
Pte = q x a
Pte = 200 Kg/m2 (ó 2 kN/m2) x 2.00 m
Pte = 400 Kg/m (ó 4 kN/m)
3
CARGA TRANSMITIDA POR EL ENTREPISO
Pep = q x a
Pep = 1.000 Kg/m2 (ó 10 kN/m2) x 2.00 m
Pep = 2.000 Kg/m (ó 20 kN/m)
4
CARGA TRANSMITIDA POR EL CIMIENTO
Pci = 5 % x (1 + 2 + 3)
13. 1 CARGA TRANSMITIDA POR EL PESO DEL MURO
Pmu = P.e. x e x h
Pmu = 1.800 Kg/m3 (ó18 kN/m3) x 0,30 m x 8,00 m
Pmu = 4.320 Kg/m (ó 43,20 kN/m)
2
CARGA TRANSMITIDA POR EL TECHO
Pte = q x a
Pte = 200 Kg/m2 (ó 2 kN/m2) x 2.00 m
Pte = 400 Kg/m (ó 4 kN/m)
3
CARGA TRANSMITIDA POR EL ENTREPISO
Pep = q x a
Pep = 1.000 Kg/m2 (ó 10 kN/m2) x 2.00 m
Pep = 2.000 Kg/m (ó 20 kN/m)
4
CARGA TRANSMITIDA POR EL CIMIENTO
Pci = 5 % x (1 + 2 + 3)
Pci = 5 / 100 x (4.320 + 400 + 2.000) (ó 43,2 + 4 +20)
14. 1 CARGA TRANSMITIDA POR EL PESO DEL MURO
Pmu = P.e. x e x h
Pmu = 1.800 Kg/m3 (ó18 kN/m3) x 0,30 m x 8,00 m
Pmu = 4.320 Kg/m (ó 43,20 kN/m)
2
CARGA TRANSMITIDA POR EL TECHO
Pte = q x a
Pte = 200 Kg/m2 (ó 2 kN/m2) x 2.00 m
Pte = 400 Kg/m (ó 4 kN/m)
3
CARGA TRANSMITIDA POR EL ENTREPISO
Pep = q x a
Pep = 1.000 Kg/m2 (ó 10 kN/m2) x 2.00 m
Pep = 2.000 Kg/m (ó 20 kN/m)
4
CARGA TRANSMITIDA POR EL CIMIENTO
Pci = 5 % x (1 + 2 + 3)
Pci = 5 / 100 x (4.320 + 400 + 2.000) (ó 43,2 + 4 +20)
Pci = 336 Kg/m (ó 3,36 kN/m)
15. 1 CARGA TRANSMITIDA POR EL PESO DEL MURO
Pmu = P.e. x e x h
Pmu = 1.800 Kg/m3 (ó18 kN/m3) x 0,30 m x 8,00 m
Pmu = 4.320 Kg/m (ó 43,20 kN/m)
2
CARGA TRANSMITIDA POR EL TECHO
Pte = q x a
Pte = 200 Kg/m2 (ó 2 kN/m2) x 2.00 m
Pte = 400 Kg/m (ó 4 kN/m)
3
CARGA TRANSMITIDA POR EL ENTREPISO
Pep = q x a
Pep = 1.000 Kg/m2 (ó 10 kN/m2) x 2.00 m
Pep = 2.000 Kg/m (ó 20 kN/m)
4
CARGA TRANSMITIDA POR EL CIMIENTO
Pci = 5 % x (1 + 2 + 3)
Pci = 5 / 100 x (4.320 + 400 + 2.000) (ó 43,2 + 4 +20)
Pci = 336 Kg/m (ó 3,36 kN/m)
T CARGA TOTAL TRANSMITIDA AL TERRENO
PT = 4.320 + 400 + 2.000 + 336 = 7.056 Kg/m
( ó 43,20 + 4,00 + 20,00 + 3,36 = 70,56 kN/m)
19. PARA EL DIMENSIONAMIENTO DE LAS ZAPATAS CORRIDAS
ANALIZAMOS 1 (UN) METRO LINEAL DE ZAPATA:
CARGA TOTAL POR METRO P = 7.056 Kg/m (70,56 kN/m)
TENSIÓN ADMISIBLE σadm = 1,0 Kg/cm2 (10 N/cm2)
20. PARA EL DIMENSIONAMIENTO DE LAS ZAPATAS CORRIDAS
ANALIZAMOS 1 (UN) METRO LINEAL DE ZAPATA:
CARGA TOTAL POR METRO P = 7.056 Kg/m (70,56 kN/m)
TENSIÓN ADMISIBLE σadm = 1,0 Kg/cm2 (10 N/cm2)
SABEMOS QUE: σ = P / S
21. PARA EL DIMENSIONAMIENTO DE LAS ZAPATAS CORRIDAS
ANALIZAMOS 1 (UN) METRO LINEAL DE ZAPATA:
CARGA TOTAL POR METRO P = 7.056 Kg/m (70,56 kN/m)
TENSIÓN ADMISIBLE σadm = 1,0 Kg/cm2 (10 N/cm2)
SABEMOS QUE: σ = P / S ES DECIR: σ = P / a x 1 m
22. PARA EL DIMENSIONAMIENTO DE LAS ZAPATAS CORRIDAS
ANALIZAMOS 1 (UN) METRO LINEAL DE ZAPATA:
CARGA TOTAL POR METRO P = 7.056 Kg/m (70,56 kN/m)
TENSIÓN ADMISIBLE σadm = 1,0 Kg/cm2 (10 N/cm2)
SABEMOS QUE: σ = P / S ES DECIR: σ = P / a x 1 m → a = P / σ x 1 m
23. PARA EL DIMENSIONAMIENTO DE LAS ZAPATAS CORRIDAS
ANALIZAMOS 1 (UN) METRO LINEAL DE ZAPATA:
CARGA TOTAL POR METRO P = 7.056 Kg/m (70,56 kN/m)
TENSIÓN ADMISIBLE σadm = 1,0 Kg/cm2 (10 N/cm2)
SABEMOS QUE: σ = P / S ES DECIR: σ = P / a x 1 m → a = P / σ x 1 m
7.056 Kg
1 Kg/cm2 x 100 cm.
a =
705.600 N
10 N/cm2 x 100 cm.
24. PARA EL DIMENSIONAMIENTO DE LAS ZAPATAS CORRIDAS
ANALIZAMOS 1 (UN) METRO LINEAL DE ZAPATA:
CARGA TOTAL POR METRO P = 7.056 Kg/m (70,56 kN/m)
TENSIÓN ADMISIBLE σadm = 1,0 Kg/cm2 (10 N/cm2)
SABEMOS QUE: σ = P / S ES DECIR: σ = P / a x 1 m → a = P / σ x 1 m
7.056 Kg
1 Kg/cm2 x 100 cm.
a =
705.600 N
10 N/cm2 x 100 cm.
25. PARA EL DIMENSIONAMIENTO DE LAS ZAPATAS CORRIDAS
ANALIZAMOS 1 (UN) METRO LINEAL DE ZAPATA:
CARGA TOTAL POR METRO P = 7.056 Kg/m (70,56 kN/m)
TENSIÓN ADMISIBLE σadm = 1,0 Kg/cm2 (10 N/cm2)
SABEMOS QUE: σ = P / S ES DECIR: σ = P / a x 1 m → a = P / σ x 1 m
7.056 Kg
1 Kg/cm2 x 100 cm.
a =
a ≈ 70 cm.
705.600 N
10 N/cm2 x 100 cm.
26. ZAPATA CORRIDA DE HORMIGÓN SIMPLE
a = 70 cm.
≥ 7,5 cm 30 cm ≥ 7,5 cm
70 cm
h=?
27. ZAPATA CORRIDA DE HORMIGÓN SIMPLE
a = 70 cm.
≥ 7,5 cm 30 cm ≥ 7,5 cm
70 cm
h=?
28. ZAPATA CORRIDA DE HORMIGÓN SIMPLE
a = 70 cm.
≥ 7,5 cm 30 cm ≥ 7,5 cm
70 cm
h=?
h = 70 cm. – 30 cm.
2
29. ZAPATA CORRIDA DE HORMIGÓN SIMPLE
a = 70 cm.
≥ 7,5 cm 30 cm ≥ 7,5 cm
70 cm
h=?
h = 70 cm. – 30 cm.
2
h = 20 cm.
30. ZAPATA CORRIDA DE HORMIGÓN POBRE
a = 70 cm.
≥ 7,5 cm 30 cm ≥ 7,5 cm
70 cm
h=?
31. ZAPATA CORRIDA DE HORMIGÓN POBRE
a = 70 cm.
≥ 7,5 cm 30 cm ≥ 7,5 cm
70 cm
h=?
32. ZAPATA CORRIDA DE HORMIGÓN POBRE
a = 70 cm.
≥ 7,5 cm 30 cm ≥ 7,5 cm
70 cm
h = 1,73 x (70 cm. – 30 cm.)
2h=?
33. ZAPATA CORRIDA DE HORMIGÓN POBRE
a = 70 cm.
≥ 7,5 cm 30 cm ≥ 7,5 cm
70 cm
h = 1,73 x (70 cm. – 30 cm.)
2
h = 35 cm.
h=?
34. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
30 cm
70 cm
35. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1
70 cm
30 cm
36. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1 >e
70 cm
30 cm
37. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1 >e → e = 30 cm.
70 cm
30 cm
38. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1 >e → e = 30 cm. → a1 = 45 cm.
70 cm
30 cm
39. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1 >e → e = 30 cm. → a1 = 45 cm.
h
70 cm
30 cm
40. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1 >e → e = 30 cm. → a1 = 45 cm.
h = 2 o 3 HILADAS
70 cm
30 cm
41. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1 >e → e = 30 cm. → a1 = 45 cm.
h = 2 o 3 HILADAS → 2 HILADAS
70 cm
30 cm
42. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1 >e → e = 30 cm. → a1 = 45 cm.
h = 2 o 3 HILADAS → 2 HILADAS → h ≈ 15 cm.
70 cm
30 cm
43. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1 >e → e = 30 cm. → a1 = 45 cm.
h = 2 o 3 HILADAS → 2 HILADAS → h ≈ 15 cm.
r =
70 cm
30 cm
44. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1 >e → e = 30 cm. → a1 = 45 cm.
h = 2 o 3 HILADAS → 2 HILADAS → h ≈ 15 cm.
r = 7,5 cm. → 7,5 cm. → 7,5 cm.
70 cm
30 cm
45. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1 >e → e = 30 cm. → a1 = 45 cm.
h = 2 o 3 HILADAS → 2 HILADAS → h ≈ 15 cm.
r = 7,5 cm. → 7,5 cm. → 7,5 cm.
a2
70 cm
30 cm
46. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1 >e → e = 30 cm. → a1 = 45 cm.
h = 2 o 3 HILADAS → 2 HILADAS → h ≈ 15 cm.
r = 7,5 cm. → 7,5 cm. → 7,5 cm.
a2 ≥a
70 cm
30 cm
47. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1 >e → e = 30 cm. → a1 = 45 cm.
h = 2 o 3 HILADAS → 2 HILADAS → h ≈ 15 cm.
r = 7,5 cm. → 7,5 cm. → 7,5 cm.
a2 ≥a → a = 70 cm.
30 cm
70 cm
48. ZAPATA CORRIDA DE MAMPOSTERÍA DE LADRILLOS COMUNES
a = 70 cm.
RESULTARÁ UNA ZAPATA ESCALONADA DONDE:
a1 >e → e = 30 cm. → a1 = 45 cm.
h = 2 o 3 HILADAS → 2 HILADAS → h ≈ 15 cm.
r = 7,5 cm. → 7,5 cm. → 7,5 cm.
a2 ≥ a → a = 70 cm. → a2 = 75 cm.
70 cm
30 cm
49. VIGA DE ENCADENADO Y PILOTES
30 cm.
30 cm.
15
= ?
(1,35 m.)
(1,35 m.)(1,35 m.)
CARGA TRANSMITIDA POR EL MURO A CADA PILOTE (P)
50. VIGA DE ENCADENADO Y PILOTES
30 cm.
30 cm.
15
= ?
(1,35 m.)
(1,35 m.)(1,35 m.)
CARGA TRANSMITIDA POR EL MURO A CADA PILOTE (P)
P = Q x L1
51. VIGA DE ENCADENADO Y PILOTES
30 cm.
30 cm.
15
= ?
(1,35 m.)
(1,35 m.)(1,35 m.)
CARGA TRANSMITIDA POR EL MURO A CADA PILOTE (P)
P = Q x L1 = 7.056 Kg/m x 1,35 m = 9.526 Kg
(70,56 kN/m) (95,26 kN/m)
52. VIGA DE ENCADENADO Y PILOTES
30 cm.
30 cm.
15
= ?
(1,35 m.)
(1,35 m.)(1,35 m.)
CARGA TRANSMITIDA POR EL MURO A CADA PILOTE (P)
P = Q x L1 = 7.056 Kg/m x 1,35 m = 9.526 Kg
(70,56 kN/m) (95,26 kN/m)
DETERMINACIÓN DEL DIÁMETRO DEL PILOTE (Φ)
53. VIGA DE ENCADENADO Y PILOTES
30 cm.
30 cm.
15
= ?
(1,35 m.)
(1,35 m.)(1,35 m.)
CARGA TRANSMITIDA POR EL MURO A CADA PILOTE (P)
P = Q x L1 = 7.056 Kg/m x 1,35 m = 9.526 Kg
(70,56 kN/m) (95,26 kN/m)
DETERMINACIÓN DEL DIÁMETRO DEL PILOTE (Φ)
Φ = 30 cm = 0,30 m (fijado por el proyectista).
54. σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
CÁLCULO DE LA CARGA A SER TRANSMITIDA POR LA PUNTA DEL PILOTE AL
TERRENO POR COMPRESIÓN:
55. σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
CÁLCULO DE LA CARGA A SER TRANSMITIDA POR LA PUNTA DEL PILOTE AL
TERRENO POR COMPRESIÓN:
σ= P / S →
56. σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
CÁLCULO DE LA CARGA A SER TRANSMITIDA POR LA PUNTA DEL PILOTE AL
TERRENO POR COMPRESIÓN:
σ= P / S → P = σ x S →
57. σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
CÁLCULO DE LA CARGA A SER TRANSMITIDA POR LA PUNTA DEL PILOTE AL
TERRENO POR COMPRESIÓN:
σ= P / S → P = σ x S → Ppta = σadm x Spta → Ppta = σadm x (πx R2)
58. σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
CÁLCULO DE LA CARGA A SER TRANSMITIDA POR LA PUNTA DEL PILOTE AL
TERRENO POR COMPRESIÓN:
σ= P / S → P = σ x S → Ppta = σadm x Spta → Ppta = σadm x (πx R2)
Ppta = 1,00 Kg/cm2 (ó 10 N) x 3,14 x (15 cm)2
59. σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
CÁLCULO DE LA CARGA A SER TRANSMITIDA POR LA PUNTA DEL PILOTE AL
TERRENO POR COMPRESIÓN:
σ= P / S → P = σ x S → Ppta = σadm x Spta → Ppta = σadm x (πx R2)
Ppta = 1,00 Kg/cm2 (ó 10 N) x 3,14 x (15 cm)2
60. σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
CÁLCULO DE LA CARGA A SER TRANSMITIDA POR LA PUNTA DEL PILOTE AL
TERRENO POR COMPRESIÓN:
σ= P / S → P = σ x S → Ppta = σadm x Spta → Ppta = σadm x (πx R2)
Ppta = 1,00 Kg/cm2 (ó 10 N) x 3,14 x (15 cm)2 → Ppta = 706 Kg
(ó 7.065 N = 7,06 kN)
61. σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
CÁLCULO DE LA CARGA A SER TRANSMITIDA POR LA PUNTA DEL PILOTE AL
TERRENO POR COMPRESIÓN:
σ= P / S → P = σ x S → Ppta = σadm x Spta → Ppta = σadm x (πx R2)
Ppta = 1,00 Kg/cm2 (ó 10 N) x 3,14 x (15 cm)2 → Ppta = 706 Kg
CÁLCULO DE LA CARGA REMANENTE, A SER TRANSMITIDA POR EL FUSTE DEL
PILOTE AL TERRENO POR FRICCIÓN:
Pfri = P - Ppta
(ó 7.065 N = 7,06 kN)
62. σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
CÁLCULO DE LA CARGA A SER TRANSMITIDA POR LA PUNTA DEL PILOTE AL
TERRENO POR COMPRESIÓN:
σ= P / S → P = σ x S → Ppta = σadm x Spta → Ppta = σadm x (πx R2)
Ppta = 1,00 Kg/cm2 (ó 10 N) x 3,14 x (15 cm)2 → Ppta = 706 Kg
CÁLCULO DE LA CARGA REMANENTE, A SER TRANSMITIDA POR EL FUSTE DEL
PILOTE AL TERRENO POR FRICCIÓN:
Pfri = P - Ppta → Pfri = 9.526 Kg – 706 Kg → Pfri = 8.820 Kg
(ó 7.065 N = 7,06 kN)
(ó 95,26 Kn) (7,06 kN) (88,20 kN)
63. CÁLCULO DE LA SUPERFICIE LATERAL DEL PILOTE (FUSTE):
h= ?
P= 8.820 Kg
(88,20 kN)
σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
64. CÁLCULO DE LA SUPERFICIE LATERAL DEL PILOTE (FUSTE):
t = Pfri / Sfri
h= ?
σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
P= 8.820 Kg
(88,20 kN)
65. CÁLCULO DE LA SUPERFICIE LATERAL DEL PILOTE (FUSTE):
t = Pfri / Sfri → Sfri = Pfri / t
h= ?
σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
P= 8.820 Kg
(88,20 kN)
66. CÁLCULO DE LA SUPERFICIE LATERAL DEL PILOTE (FUSTE):
t = Pfri / Sfri → Sfri = Pfri / t
Sfri = 8.820 Kg / 0,30 Kg/cm2 → Sfri = 29.400 cm2
h= ?
σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
P= 8.820 Kg
(88,20 kN)
(88,20 kN) (0,003 kN/cm2)
67. CÁLCULO DE LA SUPERFICIE LATERAL DEL PILOTE (FUSTE):
t = Pfri / Sfri → Sfri = Pfri / t
Sfri = 8.820 Kg / 0,30 Kg/cm2 → Sfri = 29.400 cm2
CÁLCULO DE LA ALTURA DEL PILOTE:
h= ?
σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
P= 8.820 Kg
(88,20 kN)
(88,20 kN) (0,003 kN/cm2)
68. CÁLCULO DE LA SUPERFICIE LATERAL DEL PILOTE (FUSTE):
t = Pfri / Sfri → Sfri = Pfri / t
Sfri = 8.820 Kg / 0,30 Kg/cm2 → Sfri = 29.400 cm2
CÁLCULO DE LA ALTURA DEL PILOTE:
Slat = πx d x h →
h= ?
σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
P= 8.820 Kg
(88,20 kN)
(88,20 kN) (0,003 kN/cm2)
69. CÁLCULO DE LA SUPERFICIE LATERAL DEL PILOTE (FUSTE):
t = Pfri / Sfri → Sfri = Pfri / t
Sfri = 8.820 Kg / 0,30 Kg/cm2 → Sfri = 29.400 cm2
CÁLCULO DE LA ALTURA DEL PILOTE:
Slat = πx d x h → h =
h= ?Slat
π x d
σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
P= 8.820 Kg
(88,20 kN)
(88,20 kN) (0,003 kN/cm2)
70. CÁLCULO DE LA SUPERFICIE LATERAL DEL PILOTE (FUSTE):
t = Pfri / Sfri → Sfri = Pfri / t
Sfri = 8.820 Kg / 0,30 Kg/cm2 → Sfri = 29.400 cm2
CÁLCULO DE LA ALTURA DEL PILOTE:
Slat = πx d x h → h =
h = → h = 312 cm
(3,12 m)
h= ?Slat
π x d
29.400 cm2
3,14 x 30 cm
σadm = 1,00 Kg/cm2 (dato) (10 N/m) tadm = 0,30 Kg/cm2 (dato) (3 N/m)
P= 8.820 Kg
(88,20 kN)
(88,20 kN) (0,003 kN/cm2)
